USA Made Compact Pendulum Quartz Clock Movement (up to 3/4" thick dial face)

Average rating:
average rating 89%
11 reviews
Explore all reviews
Quantity   1 - 9     10 - 49     50+
Price $21.95 $16.50 $15.50
Per Each Movement - Hands and Pendulum by Selection Only
US NO TAX, Part #: Q-37
Quantity:

Checkout/Estimate Shipping

Compact Pendulum Quartz Clock Movements (up to 3/4" thick dial face)

These Pendulum Clock Mechanisms are ideal for compact clock cases. These clock motors run ;a step second hand on a single 'AA' battery and comes with a 1 year warranty and is USA Made. Fantastic replacement clockworks, or easy to use to make new clocks.

Mini Pendulum Mechanism Features:

  • Mini Pendulum Movement Size 2-1/8 inches wide x 3-5/8 inches high x 7/8 inches deep.
  • 1 year Warranty
  • USA Made
  • Step Second Hand (optional)
  • Powered by AA Battery (Not Included)
  • Mounting hardware (washer, hex nut, open end nut) included. Hanger sold separately.

Compact Pendulum Clock Mechanism Shopping Tips:

1) Choose your movement based on the thickness of the clock face/dial you are using or making. Learn how to choose the right size clock hands and clock motors.

2) Mix and Match Sizes of Pendulum Clock Movements to get a better price.

3) If you forget to add hands or the pendulum rod/bob and you'd still like the hands or rod and bob a separate shipping fee will apply.  We always recommend new hands, as older hands may not fit the American I Shaft design.

Shop here for your Pendulums and Hands to Go With This Pendulum Quartz Clock Motor Mounting hardware (washer, hex nut, open end nut) included. Hanger sold separately.

Specifications

**When repairing a clock we always recommend new hands as your old ones may not fit.


  • Dimensions:2-1/8 inches wide x 3-5/8 inches high x 7/8 inches deep/li>
  • Overall Shaft Length:1-1/4"
  • Threaded Shaft Diameter:5/16"
  • Threaded Shaft Length: 7/8"
  • Runs on 1 AA battery
  • Runs hands up to 4-7/8" inches long
  • Works with Material up to 3/4" thick

  • The maximum capacity for pendulums on this movement is 100 grams (3-1/2 ounces).
  • Pendulums swing without battery power - using momentum and magnet. Keep your clock level and perpendicular to the ground for continuous pendulum motion. For a battered powered pendulum consider our Heavy Duty Pendulum Drive QB-DRV

  • Hardware Included

  • Brass Washer
  • Hex Nut
  • Open End Nut
  • Hanger Sold Separately



  • Optional Hardware

    Add an Black Endcap for $0.50
    or Add an Endcap for $0.50

    Average rating:
    average rating 89%
    11 reviews

    Write a Review || Explore all reviews

    Featured positive reviews:

    average rating 80%
    Clock movement perfect retrofit 02/25/2019
    By Dan N
    Unit was replacement for an 'art-clock' that had fallen & jammed the stems. Unit swapped in perfectly, no fussing or rework required, and clock is working great again. Happy for a resource like Bear Woods.
    average rating 100%
    Rudi 07/27/2018
    By Rudy Kroon
    Everything fitted fine, the repaired click runs good. You handled my order well and friendly. I will not hesitate to deal with you again in the future. Thank you
    average rating 80%
    great quality 08/09/2022
    By William
    + The movement sure is better quality then some of the lesser expensive movements purchased in the past.
    - shipping time was longer then first stated
    average rating 100%
    Product is great 04/08/2023
    By William Dejonghe
    All battery operated clocks are not the same, the ones purchased from Bear Woods, are a bit more expensive, but truly, are the best I have ever used.
    average rating 100%
    Kept my 45 year old clock running. 06/06/2022
    By Richard Kolb
    Nice quality. I was able to adapt this to my 45 - year old craft clock to keep it running.
    average rating 100%
    Clock works again! 12/30/2022
    By Eugene Fields
    Had to order hands longer than needed but was able to adapt them.
    average rating 100%
    Exactly what I needed 01/12/2023
    By William Brown
    What u described is what I ordered and is what I received!
    average rating 100%
    Both 11/02/2022
    By Richard Maddin
    Totally satisfied with all aspects of the transaction.
    average rating 100%
    Pendulum clock movement 09/03/2018
    By Cinda Phillips
    just as pictured, works well in my clock.
    average rating 100%
    work 02/17/2018
    By Evan Hedrick
    work great

    Tips

    Install a FRESH Duracell or Energizer Battery (But not a rechargeable type).  In our experience, these are the only batteries that are reliable for clock mechanisms. Sometimes you will even try a separate pack as not all new packs have perfect batteries.

    Choose hands - the options here will fit your clock motor. We recommend our new, balanced hands.
